HMI Comfort Touch Panel PC 15.6" Screen Diagonal 1920x1080 Physical Resolution
| Place of Origin | China |
|---|---|
| Brand Name | ITD/OEM |
| Certification | CE/ROHS/FCC |
| Model Number | ITD156PPCT5** |
| Minimum Order Quantity | 1PCS |
| Price | TBA |
| Packaging Details | Foam,gift box,master carton,wooden case,pallet |
| Delivery Time | 15-20 working days |
| Payment Terms | T/T, Western Union,Paypal |
| Supply Ability | 10000 unit per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| CPU | Intel J1900/i3/i5/i7/RK3288 | Screen Diagonal | 15.6" |
|---|---|---|---|
| Display Active Screen Size | 344.16(W) × 193.59(H)mm | Physical Resolution | 1920X1080 |
| Compliance | CE,FCC,ROHS | Optional Functions | Web Camera, Speakers, RFID, NFC, Fingerprint, QR Reader, GPS |
| High Light | touch panel computer,touch monitor pc |
||
Product Description
15.6" muli-touch screen HMI comfort touch panel PC built-in RIFD,NFC,Fingerprint,QR rearder,web camera,GPS
ITD 15.6” multi-touch screen HMI comfort panel PC is fully-integrated‚ multi capacitive touch screen combines high-performance Intel® Core™ Dual/Quad Core Processor i3/i5/i7, and Projected Capacitive Touch (PCT or PCAP)Technology in industrial-grade LCD flat panels, combined with a NFC or RFID reader with sleek and flat front surface industrial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10 multi-touch interactive experiences. The ITD 15.6” multi-touch HMI comfort panel PC specifically suited for various smart access control systems.
Specifications
| Panel | Cell Type/Glass Surface | TFT |
| Size | 15.6” | |
| Aspect Ratio | 16:9 | |
| Active Area | 344.16(W) × 193.59(H)mm | |
| Pixel Pitch | 0.17925 × 0.17925mm | |
| Native Resolution | 1920 x 1080 | |
| Colors | 16.7M | |
| Brightness | 300cd/㎡ | |
| Contrast | 500:1 | |
| Response Time | 14ms | |
| Viewing Angle(Typical) | 160/160 | |
| Light Source | LED Backlight with 50000Hours’Lifetime |
SPECIFICATION
| System | CPU | Intel® Core i3/i5/i7 Processor |
| BIOS | Award BIOS 4/8Mbit SPI Flash ROM | |
| Chipset | Intel Valley View SSA‐Cunit | |
| Memory | 1 x SO-DIMM, DDR3 1333MHz Memory, 4GB, Max.16GB | |
| Graphic Chipset | CPU integrated graphics HD and support 1080p | |
| Storage | 64G SSD | |
| LAN | 1 x 10/100/1000Mbps Ethernet | |
| Input / Output | Serial Ports | 1 x COM |
| USB Ports | 4 X USB | |
| VGA Port | 1 x VGA | |
| HDMI Port | 1x HDMI Output | |
| Audio Card |
with Realtek ALC662 Line-In/Line-Out/Speaker out with 3W AMP Circuit/MIC IN |
|
| Power | Input Voltage | DC 12V |
| Operation/Power Saving | 58W | |
| Environment Considerations | Operating Temperature | -10~60℃ |
| Storage Temperature | -20~70℃ | |
| Relative Humidity | 10%~90%(Non Condensing) | |
| OS Support | Windows 7/ Windows XP/ Windows 8/ Windows 10/Linux | |
| Order Information | 15.6” PCAP Touch Panel PC i3/i5/i7, NFC Reader /ITD156PPCT5KI*-NFC | |
| 15.6” Non Touch Panel PC i3/i5/i7, NFC Reader /ITD156PPCG1KI*-NFC | ||
| 15.6” PCAP Touch Panel PC i3/i5/7, RFID Reader /ITD156PPCT5KI*-RFID | ||
| 15.6” Non Touch Panel PC i3/i5/i7, RFID Reader /ITD156PPCG1KI*-RFID | ||
