22 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism
1pcs
MOQ
TBA
Price
22 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: ITD
Certification: CE, FCC, RoHS
Model Number: ITD22PMT5X31
High Light:

industrial touch display

,

industrial computer monitor

Payment & Shipping Terms
Packaging Details: 1-5pcs/CTN, Safe, Firm, suitable for international shipping
Delivery Time: 5-15 Business Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000PCS/Month
Specifications
Housing Material: Steel Chassis, Aluminum Front Bezel
Housing Type: Panel/Embedded Mount, VESA Mounting
Operating Temperature: -10~60℃(-20~70℃ Optional)
Operating Humidity: 10%-90% (Non Condensing)
24/7/365 Use: Supported
Resolution: 1680*1050
Aspect Ratio: 16:10
Product Description

22 inch industrial flat bezel panel mount PCAP multi touch screen monitor display with IP65 front , anti-vandalism



ITD’s flat bezel panel mount monitor using Projected Capacitive touchscreen technology (PCAP/PCT) allows for a modern user interface thereby making use of new and extended ways of user input and control. Gesture-based interactions by touching and pointing, with one finger or more, rotate, pinch to zoom and move objects on the display.





BENEFITES

-Sealed Front Panel Design to NEMA 4/IP65

-Multi-Touch (PCT / PCAP) Touchscreen

-Rugged aluminum front bezel and aluminum alloy back chassis

-VGA/HDMI/DVI video connectors

-Easy to Service & Maintain in the field

-LED Backlight with 50000h

Flat Bezel Panel Mount LCD Monitor



Model Name ITD22PMN1X31
IP Rating N/A

LCD Panel



Screen Diagonal (Inch) 22”
Display Active Screen Size (cm) 473.76(H)×296.1(V)
Aspect Ratio 16:10
Physical Resolution 1680×1050
Maximum Resolution Supported 1920×1200
Colors 16.7M
Brightness (cd/m²) 250
Contrast Ratio 1000:1
View Angels 85/85/80/80
Backlight/Backlight Lifetime LED Backlight with 50000Hours’Lifetime

Touch Panel



Touch Options Resistive, PCAP
Touch Drivers Windows, Linux, Android, Mac, Raspberry Pi

Input / Output



Video Input 1 × VGA
1 × DVI-I
1 × HDMI
Audio 1 × PC-Audio
Touch Connector 1 × USB
Power Connector 1 × DC2.0

Operation



Operating Temperature Range -10~60°C (-20~70°C Optional)
Humidity Range (RH) 10-90%
24/7/365 Use Supported

Power



Power Indicator Green LED
Power Input DC 12V
Power Consumption 26.25W

Order Information



22”Panel Mount LCD Monitor with Resistive Touch ITD22PMT1X31
22”Panel Mount LCD Monitor with PCAP Touch ITD22PMT5X31
22”Panel Mount LCD Monitor with Tempered Glass ITD22PMG1X31

22 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism 022 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism 1



APPLICATION

22 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism 2



OUR FACTORY
22 Inch Panel Mount Industrial Touch Screen Monitor Flat Bezel , Anti - Vandalism 3
