46" Zero Bezel Digital Signage Displays RS232 Remote Control Digital Advertising Screens
46" Zero Bezel Digital Signage Displays RS232 Remote Control Digital Advertising Screens
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: ITD
Certification: CE, FCC, RoHS
Model Number: ITD46VWN1Z1
High Light:

digital signage screens


digital advertising screens

Payment & Shipping Terms
Packaging Details: 1-5pcs/CTN, Safe, Firm, suitable for international shipping
Delivery Time: 5-15 Business Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000PCS/Month
Housing Material: Steel Chassis, Aluminum Frame
Color: Black Or Silver
Housing Type: VESA Mounting, Desktop Stand
MTBF: 50000Hours
Operating Temperature: -10~60℃(-20~70℃ Optional)
Operating Humidity: 10%-90% (Non Condensing)
24/7/365 Use: Supported
Product Description

46" ITD patented true zero-bezel optical video wall screen display FHD RS232 remote control


ITD true zero-bezel high-quality LCD video walls deliver a new level of visual performance for ITD's patent awarded of LCD video wall solutions featuring the true zero bezels, most flexible mounting systems and slimmest installation depths, which are best-in-class. ITD's innovative LCD video wall solutions are specifically designed to deliver precise and brilliant visual messages in the world's most demanding environments--from control rooms to digital signage and architectural applications. This immersive, flexible video wall combines the ultra-thin profile zero bezel LCD with improvements in design, installation and service, which have been widely applied in retail showrooms, waiting rooms, production floors, churches, temples, corporate offices, theaters, parks, shopping malls, casino, hotel, bars and anywhere you would like to show advertisements, information, TV programs, sports and any media contents.




Zero-Bezel Video Wall Screen


Model Name ITD46VWN1Z1
IP Rating N/A

Input / Output


1 × DVI-D

1 × VGA

1 × HDMI

3 × AV Input

1 × AV Output

1 × DP Input

1 × DP Output (Optional)

LCD Panel


Screen Diagonal (Inch/cm) 46”
Display Active Screen Size (cm) 1018.08(H)×572.67(V)
Aspect Ratio 16:9
Physical Resolution 1980×1080
Maximum Resolution Supported 1920×1080
Colors 16.7M
Brightness (cd/m²) 500 (700 Optional)
Contrast Ratio 3500:1
View Angels 89/89/89/89
Backlight/Backlight Lifetime LED Backlight with 50000Hours' Lifetime



Operating Temperature Range 0~50°C
Humidity Range (RH) 10-90%
24/7/365 Use Supported

Mounting Method


Wall Mounted

Floor Standing

Cabinet Floor Standing

Front Access Door Open Bracket

Power /Speakers
Power Indicator Green LED
Power Input Internal Power Supply AC100V~240V

Power Consumption




Order Information


46”500nits Zero-Bezel Video Wall Screen with Wall Mounted Brackets ITD46VWN1Z1
46”700nits Zero-Bezel Video Wall Screen with Wall Mounted Brackets ITD46VWN1Z2



  • Exceptional quality and commercial-grade reliability and performance
  • Ultra-Slim, Energy-Efficient LED Backlight Technology
  • All steel construction designed for harsh & public environments
  • Patented the world’s first true Zero-Bezel LCD
  • Uniform brightness, stable image, superior visual performance, no flickering and fuzzy
  • Ultra long lifetime with 80,000 hours, engineered for 7/24 mission-critical reliability
  • Configured with different groups: 2×2, 3×3, 4×4, 256pcs max. (Landscape or Portrait).
  • Combining with ITD graphics processor & matrix supporting max. 256pcs of splicing LCD screens in one video wall
  • Hardware architecture controlled by green control software with plug and play
