IP65 Front 86" Industrial Panel Mount Monitor Flat Surface 410 Nits Brightness
IP65 Front 86" Industrial Panel Mount Monitor Flat Surface 410 Nits Brightness
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: ITD
Certification: CE, FCC, RoHS
Model Number: ITD86OFT5P1
High Light:

industrial computer monitor


waterproof lcd monitor

Payment & Shipping Terms
Packaging Details: 1-5pcs/CTN, Safe, Firm
Delivery Time: 10-15 Business Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000PCS/Month
Color: Black,Silver,golden
Aspect Ratio: 16:9
Resolution: 3840x 2160
Operating Humidity: 10%-90% (Non Condensing)
24/7/365 Use: Supported
Viewing Angle: 89/89/89/89
Brightness: 410 Nits
Product Description

flat panel true flat surface IP65 front 86" industrial pcap touch screen monitor


ITD’s line of projected capacitive touch displays are engineered specifically for industrial/commercial customers who are looking for a rugged and durable touch screen without having to sacrifice on image quality. Featuring an edge to edge zero bezel design, the touchscreen monitor can easily be wiped clean, thereby eliminating having to worry about dust and dirt collection, which helps extend the use of your display. The PCAP touchscreen LCD monitors can not only used alone as VESA wall mounted or on table with desktop stand, but also can come with side mounting brackets as open frame rear mounted in cabinets. ITD industrial multi touch displays are accurate, responsive and easy-to-use, enabling migration of existing single touch applications to a gesture-based interface that creates and delivers popular user interactions such as pan, zoom and rotate, which ideal for retail, kiosks and interactive digital signage.



  • All steel/aluminum construction provides rugged frame for public use environments
  • Ten independent touch points, plug and play
  • Eliminates dust and debris build-up at the edge and corners of the display
  • Provides improved power efficiency and reduced consumption
  • Responds to a light touch in activating response
  • Easy-to-clean surface without bezels
  • Long lasting product cycle for continuity thru all phases of project

Zero-Bezel PCAP Touchscreen Monitor


Model Name ITD86OFT5P1
IP Rating IP65 Front Panel

LCD Panel


Screen Diagonal (Inch/cm) 86”
Display Active Screen Size (mm) 1895.04(H) x 1065.96(V)
Aspect Ratio 16:9
Physical Resolution 3840×2160
Maximum Resolution Supported 3840×2160
Colors 16.7M
Brightness (cd/m²) 410nits
Contrast Ratio 1200:1
View Angels 89/89/89/89
Backlight/Backlight Lifetime LED Backlight with 50000 Hours’ Lifetime

Touch Panel


Touch Technology Projected Capacitive Touch
Touch Drivers Windows, Linux, Android, Mac, Raspberry Pi
Touch Life 50,000,000times/click
Surface Hardness 7H

Input / Output


Video Input 1 × VGA
1 × DVI-I
1 × HDMI
Audio 1 × PC-Audio
Touch Connector 1 × USB
Power Connector 1 × DC2.0



Operating Temperature Range -10~60°C (-20~70°C Optional)
Humidity Range (RH) 10-90%
24/7/365 Use Supported



Power Indicator Green LED
Power Input  AC100-240V
Power Consumption Below 408W



Side Mounting Brackets, Desktop Stand, VESA Mounting Brackets, Webcam

Order Information


86”Non Touch Monitor with Tempered Glass ITD86OFG1P1
