1080P Full HD Industrial All In One PC Touch Screen 15.6" Widescreen Panel Mounted
| Place of Origin | China |
|---|---|
| Brand Name | ITD/OEM |
| Certification | CE/ROHS/FCC |
| Model Number | ITD156PPCT5KXE31 |
| Minimum Order Quantity | 1PCS |
| Price | TBA |
| Packaging Details | Foam,gift box,master carton,wooden case,pallet |
| Delivery Time | 7-12 work days |
| Payment Terms | T/T, Western Union,Paypal |
| Supply Ability | 10000 unit per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Active Area | 344.23(H)x 193.53(V) Mm | Native Resolution | 1366 X 768(1920 X 1080 Optional) |
|---|---|---|---|
| Colors | 16.2M | Brightness | 300 Cd/m2 |
| Viewing Angle(Typical) | 85/85/80/80 (89/89/89/89 Optional) | CPU | ARM Quad Core RK3288,Main CPU Frequency:1.8GHz |
| OS | Android 5.1/6.0 | SD RAM | 2G; 4G Optional |
| High Light | touch panel computer,touch monitor pc |
||
Product Description
1080P full HD 15.6"widescreen Android PC true flat aluminum front bezel panel mounted
Specs:
| Panel | Cell Type/Glass Surface | TFT |
| Size/ Aspect Ratio | 15.6”/16:9 | |
| Active Area/ Pixel Pitch | 344.23(H)x 193.53(V) mm /0.252 × 0.252mm | |
| Native Resolution/ Colors | 1366 x 768(1920 x 1080 optional)/ 16.2M | |
| Brightness/ Contrast | 300cd/㎡/500:1 | |
| Response Time | 6ms | |
| Viewing Angle(Typical) | 85/85/80/80 (89/89/89/89 optional) | |
| Light Source | LED Backlight with 50000Hours’Lifetime |
SPECIFICATION
| System |
CPU: ARM Quad Core RK3288,Main CPU frequency:1.8GHz GPU: Mali-T764 GPU SDRAM: 2G; 4G Optional Flash: 8G: 16G/32G/64G/128G Optional OS: Android 5.1/6.0; Bluetooth: Optional Video Decoder: 4K VP8 and 4K 10bits H265/H264 1080P other video decoders (VC-1, MPEG-1/2/4, VP8) Media Format: Supports RMVB,FLV,MPEG1/2/4,AVI,WMV,MOV,MP4,TS,etc Music Format: Support MP3/AAC/WAV/WMA/Dolby True HD/DTS-HD/LPCM /H264/VP8/MVC Photo Format: Supports JPG/BMP/GIF/TIFF/PNG |
| Input / Output |
1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG; 4 × COM; 1 × TF Card Support 8~128GB; 1 × DC 12V 2.0; 3G/4G Optional 1 × RJ45 LAN Ethernet 10/100/1000M (Realtek RTL8211E); |
| Operating Temperature | -10~60℃ (-20~70℃ Optional) |
| Storage Temperature | -20~70℃ |
| Relative Humidity | 10%~90% |
| Order Information | 15.6”Flat Bezel Android Panel PC with PCAP Touch/ITD156PPCT5KXE31 |
| 15.6”Flat Bezel Android Panel PC with Resistive Touch/ITD156PPCT1KXE31 | |
| 15.6”Flat Bezel Android Panel PC with Tempered Glass/ITD156PPCG1XE31 |
Image:
FEATURES
• Centralized server controls content distribution;
• Combined hardware and software solution for fast, reliable delivery of digital signage content and continuous operation;
• Easy WIFI network system installation without the need for extra IT, firewall or security configurations;
• Simple content scheduling and updating for each display;
• Restart and update digital signage players remotely;
• Create and update separate schedules for each display, al owing for targeted ads at each terminal or different locations;
• Deliver rich media including: Multiple video and audio formats, RSS feeds and image slide shows;
• Transfer schedules and contents to one or more displays;
• Control, monitor and design screen layouts remotely by the admin software;
• Support Multi-zone terminal display and flexible screen layout;
• Local review of multi-zone display layout once the content is stored in the server PC;
• Manage daily power on/off time for any display or group of displays;
• Deliver high definition image content;
• Content plays automatically upon set up of schedule;
• Display live news, weather, traffic reports, emergency announcements and many other notices;
• Anytime insert emergent video file;
• Remotely report system utilization and memory usage;
• System automatically notifies administrator of any malfunction;
• Custom-features development service available from our professional software team;
• Daily, monthly display content recording;• Possible to integrate with the any existing management system.
