24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking

  • 24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking
  • 24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking
  • 24 Inch Flat LCD Monitor Touch Screen 1500nits For Smart Parking
Place of Origin China
Brand Name ITD/OEM
Certification CE, FCC, RoHS
Model Number ITD24OFT5Y1
Minimum Order Quantity 1PCS
Price TBA
Packaging Details 1-5pcs/CTN, Safe, Firm
Delivery Time 3-15 Business Days
Payment Terms T/T, Western Union, Paypal
Supply Ability 10000PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Housing Material Open Frame , Flat Screen, Flange Design Surface Treatment AG, AR, AF Optional
Mounting Type Flush Mount With Side Brackets, VESA Mounting MTBF 50000Hours
Operating Temperature -10~60℃ Touch Screen Capacitive Multi Touch Screen Or Non Touch
I/O VGA, HDMI Inputs, DC 12V Input, USB-B Port Brightness 250nits, High Brightness 1000nits, 1500nits Optional
Warranty 2 Years Applications Smart Parking
High Light

OSD controls flat lcd monitor

,

1500nits flat lcd monitor

,

TFT LCD 24 inch flat panel monitor
Leave a Message
Product Description

24 inch flat lcd monitor touch screen 1500nits for smart parking



APPLICATIONS of monitor touch screen 1500nits:

  • Warehouse&Logistics
  • Healthcare
  • Public Safety
  • Government
  • Smark Parking
  • Gas Pumps
  • Outdoor Self-Service Terminals

Description of 24 flat lcd monitor

Model ITD24OFT5Y1
IP IP65(for front panel only)
Outline Dimensions Width: 586.2mm Height: 358.2mm Depth: 54.31mm
Weight(N.W/G.W) 6.57kg
Packing Dimension TBA
LCD Type 23.6＂Active matrix TFT-LCD
Video Input VGA/HDMI
Recommend Resolution 1920×1080@60Hz,75Hz
OSD controls Allow On-Screen Adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External Brick
Input (line) Voltage: 100-240 VAC, 50-60 Hz
Output Voltage/Current: 12V at 5A
Power Consumption 24W
Mount Interface

1)VESA 75mm and 100mm

2)Rear Mounting Brackets
Regular Warranty 2 Years
Agency Approval FCC,CE,RoHS Certified

2.2 LCD Specification

Active Area(mm) 521.28(H)×293.22(V)
Resolution 1920×1080
Pixel Pitch(mm) 0.2715×0.2715
Nominal Input Voltage VDD +5V(Typ)
Viewing angle (L/R/T/B) 89°/89°/89°/89°
Contrast 3000:1
Luminance(cd/m2) 300   1000nits, 1500nits optional
Response Time(Rising/Falling) 10ms
Support Color 16.7M
Screen Scanning 60Hz
Backlight MTBF(hr) 50000h

2.3 Touch Screen Specification

Type Projected Capacitive Touch Screen
Resolution 4096×4096
Light Transmission 85%±5%
Touch Life Cycle 50 millions times
Touch Response time 5ms
Touch System Interface USB B type
Operating System Support

Plug and Play for Windows 7/8/10,Linux Kernel 3.18.12 or above

Drivers for Windows CE/XP, Android, Mac

2.4 External AC Power Adapter

Output 12V DC/4A (24V DC, 9-36V DC optional)
Input 100-240 VAC, 50-60 Hz
MTBF 50000 hr at 25°C

2.5 Environment

Operating Temp. -10～60°C (-20～70°C optional)
Storage Temp. -20～70°C
Operating RH: 10%～90% (Non Condensing)
Storage RH: 10%～90%
