Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems

  • Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems
  • Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems
  • Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems
Place of Origin China
Brand Name ITD/OEM
Certification CE, FCC, RoHS
Model Number ITD13OFT5HBY1
Minimum Order Quantity 1PCS
Price TBA
Packaging Details 1-5pcs/CTN, Safe, Firm
Delivery Time 15-20 Business Days
Payment Terms T/T,PayPal(173515844@qq.com)
Supply Ability 10000PCS/Month
Product Details
Native Resolution/Colors 1920*1080 Operating Temperature -10~60°C,-20~70°C
Input Signals VGA,HDMI Power Source External Power Supply DC12V Input
Touch Screen 10 Points Pcap Touch,resistive Touch VESA Mount 75*75
Flush Mount Supported Viewing Angles 178/178
Highlight

Open Frame Flush Mount PCAP Touch Monitor

,

Sunlight Readable LCD Display for HMI

,

Touch Monitor for Automation Systems
Leave a Message
Product Description

Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems



A rugged industrial touch monitor featuring a 13.3-inch high-brightness sunlight readable LCD display and responsive PCAP multi-touch technology. The open frame flush mount design enables seamless integration into kiosks, industrial equipment, automation systems, and outdoor applications. With excellent visibility, durable construction, and reliable 24/7 operation, it is ideal for HMI control, self-service terminals, digital signage, and embedded display solutions.



2. 1 General

Model ITD13OFT5HBYx
IP IP65(for front panel only)
Outline Dimensions TBA
Weight(N.W/G.W) TBA
Packing Dimension TBA
LCD Type 13.3＂Active matrix TFT-LCD
Video Input VGA/HDMI
Recommend Resolution 1920×1080@60Hz,75Hz
OSD controls Allow On-Screen Adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External Brick
Input (line) Voltage: 100-240 VAC, 50-60 Hz
Output Voltage/Current: 12V at 4A Max.
Power Consumption 30W
Mount Interface

1)VESA 75mm and 100mm

2)Rear Mounting Brackets
Regular Warranty 1 Year for TFT Panel, 2 Years for others
Agency Approval FCC,CE,RoHS Certified
  13.3” 1000nits Flush Mount PCAP Touch Monitor/ITD13OFT5HBY2
13.3” 1500nits Flush Mount PCAP Touch Monitor/ITD13OFT5HBY1

2.2 LCD Specification

Active Area(mm) 293.42(H)x 164.97(V)
Resolution 1920X1080
Pixel Pitch(mm) 0.2235×0.2235
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (L/R/T/B) 89°/89°/89°/89°
Contrast 700:1
Luminance(cd/m2) 1000
Response Time(Rising/Falling) 7.7/10.8ms
Support Color 16.2M/262K
Screen Scanning 60Hz
Backlight MTBF(hr) 50000h

2.3 Touch Screen Specification

Type Projected Capacitive Touch Screen (anti-glare optional)
Resolution 4096×4096
Light Transmission 85%±5%
Touch Life Cycle 50 millions times
Touch Response time 5ms
Touch System Interface USB A type (USB B optional)
Operating System Support

Plug and Play for Win 7/8/10,Linux Kernel 3.18.12 or above

Drivers for Win CE/XP, Android, Mac

2.4 External AC Power Adapter

Output 12V DC/4A (24V DC, 9-36V DC optional)
Input 100-240 VAC, 50-60 Hz
MTBF 50000 hr at 25°C

2.5 Environment

Operating Temp. -10～60°C (-20～70°C optional)
Storage Temp. -20～70°C
Operating RH: 10%～90% (Non Condensing)
Storage RH: 10%～90%





APPLICATION

Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems



OUR FACTORY
Open Frame Flush Mount PCAP Touch Monitor, Sunlight Readable LCD Display for HMI, Automation and Embedded Systems
