17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution

  • 17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution
  • 17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution
Place of Origin China
Brand Name ITD/OEM
Certification CE, FCC, RoHS
Model Number ITD17PPCT1HBFJ1
Minimum Order Quantity 1PCS
Price TBA
Packaging Details 1-5pcs/CTN, Safe, Firm
Delivery Time 15-20 Business Days
Payment Terms T/T, Western Union, Paypal
Supply Ability 5000PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Housing Material Steel Chassis Feature Sunlight Readable
Housing Type Open Frame Mount, VESA Mounting Name Waterproof Panel PC
Operating Temperature -10~60℃(-20~70℃ Optional) Brightness 1000nits
CPU J1900,1037U,I3,I5,I7 Resolution 1280*1024
High Light

17'' Waterproof Panel PC

,

Waterproof Panel PC 1280*1024 Resolution

,

Sunlight Readable IP65 Touch Screen PC
Leave a Message
Product Description

17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution


ITD's high brightness IP65 Waterproof Panel PC's Equipped with powerful Intel Processors, deliver high performance industrial sunlight readable computing with feature rich, low-profile mechanical configurations suitable for harsh environments, and are compliant to NEMA and Ingress Protection standards for front panel.





BENEFITES OF Waterproof Panel PC



- 17" Very Bright Active Matrix Sunlight Readable TFT Display; 1000 nits (cd/m2)



- High-Luminance Solid-State LED-enhanced Backlighting



- Optical Bonding of Touch Screen Directly to the Front Surface of the LCD Optional



- 500GB HDD or 126GB SSD, Bigger Capacity Optional



- NEMA 4 (IP65) - Black Powder Coat Aluminum Front Bezel



- High Environmental Performance and Reliability





- Wide Operational Temperature Range, -10°C to +60°C



Open Frame High Brightness Panel PC


Model Name ITD17PPCG1HBF**
IP Rating N/A

PC Systems Options


ARM Android Based RK3288(RK3368 optional) X86 Windows Based X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz CPU: Intel® Celeron J1900 CPU: Intel Core i3/i5/i7
Chipset: N/A Chipset: Intel® NM10 Express Chipset: Intel® HD Graphics, Support 1080p
Memory: 1G/2G Memory: 2GB(Max. 8GB) Memory: 2GB(Max. 8GB)
HDD/SSD: 8G HDD/SSD:500G/64G HDD/SSD:500G/64G
1×HDMI 1×VGA, 1×HDMI 1×VGA, 1×HDMI
1×USB 2.0 2×USB 2.0, 2×USB3.0 2×USB 2.0, 2×USB3.0
1×mini-SD slot 1×COM(RS232/422/485) 1×COM(RS232/422/485)
1×LAN 1×LAN 1×LAN
1×Audio Out 1×Audio Out, 1×MIC In 1×Audio Out, 1×MIC In
Expansion: SSD Expansion: USB, COM, Mini-PCIe Expansion: USB, COM, Mini-PCIe

LCD Panel


Screen Diagonal (Inch/cm) 17”
Display Active Screen Size (mm) 337.920(H)X270.336
Aspect Ratio 4:3
Physical Resolution 1280X1024
Maximum Resolution Supported 1920X1080
Colors 16.7M
Brightness (cd/m²) 1000(1500 Optional)
Contrast Ratio 500:1
View Angels 85/85/80/80
Backlight/Backlight Lifetime LED Backlight with 50000 Hours’ Lifetime

Touch Panel


Touch Options Resistive, IR, PCAP, SAW
Touch Drivers Windows, Linux, Android, Mac, Raspberry Pi

Operation


Operating Temperature Range -10~60°C (-20~70°C Optional)
Humidity Range (RH) 10-90%
24/7/365 Use Supported

Power


Power Indicator Green LED
Power Input DC 12V
Power Consumption 40W

Order Information


17”1000nits Open Frame Panel PC with Resistive Touch, J1900 ITD17PPCT1HBFJ1
17”1000nits Open Frame Panel PC with PCAP Touch, J1900 ITD17PPCT5HBFJ1
17”1000nits Open Frame Panel PC with IR Touch, J1900 ITD17PPCT2HBFJ1
17”1000nits Open Frame Panel PC with Tempered Glass, J1900 ITD17PPCG1HBFJ1
17”1000nits Open Frame Panel PC with Resistive Touch, i5 ITD17PPCT1HBFI5
17”1000nits Open Frame Panel PC with PCAP Touch, i5 ITD17PPCT5HBFI5
17”1000nits Open Frame Panel PC with IR Touch, i5 ITD17PPCT2HBFJ1
17”1000nits Open Frame Panel PC with Tempered Glass, i5 ITD17PPCG1HBFI5







APPLICATION
17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution 0



OUR FACTORY
17 Inch Waterproof Panel PC Sunlight Readable IP65 Touch Screen PC 1280*1024 Resolution 1
