Aluminum Alloy Pure Flat Bezel IP65 Front Resistive Pcap Touch Industrial PC Panel Mounted PC
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Native Resolution | 1920*1080 | Brightness | 250nits,1000 Nits |
|---|---|---|---|
| Viewing Angle | 89/89/89/89 | Input Signal | HDMI,VGA,DVI |
| Power Input | DC 12V (Waterproof Connector) DC24V, DC9-36V, AC100-240V Input Optional | Storage Temperature | -20~60℃ |
| Operating Temperature | 0~50℃ | ||
| High Light | Pcap Touch Industrial PC Panel,IP65 Industrial PC Panel,Aluminum Alloy Panel Mounted PC |
||
Product Description
Aluminum alloy pure flat bezel IP65 front resistive pcap touch industrial panel PC panel mounted PC
ITD 21.5” multi-touch screen HMI comfort panel PC is fully-integrated‚ multi capacitive touch screen combines high-performance Intel® Core™ Dual/Quad Core Processor i3/i5/i7, and Projected Capacitive Touch (PCT or PCAP)Technology in industrial-grade LCD flat panels, with sleek and flat front surface industrial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10 multi-touch interactive experiences. The ITD multi-touch HMI comfort panel PC specifically suited for various interactive digital signage applications.
| Panel | Cell Type/Glass Surface | TFT |
| Size | 21.5” | |
| Aspect Ratio | 16:9 | |
| Active Area | 476.64(H) x 248.25(V)mm | |
| Pixel Pitch | 0.24825 × 0.24825mm | |
| Native Resolution | 1920 x 1080 | |
| Colors | 16.7M | |
| Brightness | 250nits | |
| Contrast | 1000:1 | |
| Response Time | 5ms | |
| Viewing Angle(Typical) | 178(H)/178(V) | |
| Light Source | LED Backlight with 50000Hours’Lifetime | |
| System | CPU | Intel® Core i3/i5/i7 Processor |
| BIOS | AMI | |
| Chipset | Intel SoC Chipset | |
| Memory | 2 x DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB | |
| Graphic Chipset | Intel HD Graphics (By CPU) | |
| Storage | 1 x SATA, 1 x mSATA, Default to 64GB SSD | |
| LAN | 1 x 10/100/1000Mbps Ethernet | |
| Input/Output | Serial Ports | 1 x COM |
| USB Ports | 4 X USB | |
| VGA Port | 1 x VGA Output | |
| HDMI Port | 1x HDMI Output | |
| Audio Card |
with Realtek ALC662 Line-Out/MIC IN |
|
| Power | Input Voltage | DC 12V |
| Operation/Power Saving | 38W | |
| Environment Considerations | Operating Temperature | -10~60℃ |
| Storage Temperature | -20~70℃ | |
| Relative Humidity | 10%~90%(Non Condensing) | |
| OS Support | Windows 7/ Windows XP/ Windows 8/ Linux/Windows 10 | |
| Mounting Method | VESA, side mounting brackets optional | |
| Accessories | Power cable, Motherboard CD driver, Screws | |
| Order Information | 21” Zero-Bezel PCAP Touch Panel PC with Intel i3/ITD21PPCT5KI3 | |
| 21” Zero-Bezel PCAP Touch Panel PC with Intel i5/ITD21PPCT5KI5 | ||
| 21” Zero-Bezel PCAP Touch Panel PC with Intel i7/ITD21PPCT5KI7 | ||
| 21” Zero-Bezel Panel PC with Tempered Glass/ITD21PPCG1KI* | ||
BENEFITES
- Exceptional quality and highly engineered industrial heavy duty monitors
- Optional touchscreens like resistive and PCAP
- Ruggedized levels of NEMA 12, 4X, 4, IP52, IP56, IP65 ratings from all directions
- Solid steel and stainless steel or aluminum alloy enclosures
- IP65 sealed, Full IP65 I/O connectors protect from any particles, water, and corrosive agents
- Accuracy in high-use applications
- Long lasting product cycle for continuity thru all phases of project
